Industrial line systems are with low power consumption an ideal platform for any customized integration, industrial automation. Office Automation, Point of sales (POS), Point of Information (POI)
Display Size
15" 4:3
Resolution
XGA, 1024x768
Luminance
400cd/m2
Contrast ratio
700
Backlight
LED
Touch screen
5-wire resistive (USB)
Processor
Intel Atom D2550, 1.86GHz
BIOS
AMI BIOS
Chipset
Intel NM10 Express
Memory
2GB DDR3 1066 (4GB max.)
Flash
one external locked CFast socket
Hard drive bay
optional 2.5" SATA HDD, SSD or SATA DOM
Watch dog Timer
Programmable 1-255sec
Expansion
2 x miniPCIe
LAN
2 x Gigabit LAN with RJ45
USB
4 x USB 2.0
COM Ports
2 x DSUB 9 male
COM Port Modi
2 x RS232/422/485
VGA
2nd VGA display port DB15
Audio
1x Line out, 1 x Line in, 1 x MIC-in
Keyboard/Mouse
PS2 connector
IP Protection
IP65 front
Mounting
panel, wall, stand, VESA 100mm
Power input
12V – 30V DC
Power adapter
AC power adapter 12V
Operating Temp.
-5°C-+60°C
Storage Temp.
-20°C-+75°C
Dimensions
384 x 310 x 63mm
Part number
273
Product Name
VS-1530T
Packing list
Panel PC Power Adapter User Manual, Driver CD
